| Specification for Silent Diesel Generator | ||||||
| Rated Output | 20KVA | 25KVA | 30KVA | 50KVA | 60KVA | 100KVA |
| Voltage | 400v | 400v | 400v | 400v | 400v | 400v |
| Frequency | 50Hz | 50Hz | 50Hz | 50Hz | 50Hz | 50Hz |
| Power Factor | 0.8 Lagging | 0.8 Lagging | 0.8 Lagging | 0.8 Lagging | 0.8 Lagging | 0.8 Lagging |
| Wire type | 3 phase 4 wires | 3 phase 4 wires | 3 phase 4 wires | 3 phase 4 wires | 3 phase 4 wires | 3 phase 4 wires |
| Alternator | DGS-184E | |||||
| Excitation | Brushless | Brushless | Brushless | Brushless | Brushless | Brushless |
| Engine | YN25GB | YN27GB | YN27GBZ | 云内YN38GBZ | YN38GBZ | YN48GBZL |
| Cyinder | 4cylinder | 4cylinder | 4cylinder | 4cylinder | 4cylinder | 4cylinder |
| Bore | 90mm | 90mm | 90mm | 102mm | 102mm | 108mm |
| Stroke | 100mm | 105mm | 105mm | 115mm | 115mm | 132mm |
| Natural Inspiration | Natural apirated | Natural apirated | Natural apirated | Natural apirated | Natural apirated | Turbocharged inter-cooled |
| Chamber | Direct Injection | Direct Injection | Direct Injection | Direct Injection | Direct Injection | Direct Injection |
| Engine Output | 16kw | 20kw | 25kw | 40kw | 50kw | 80kw |
| Rotation | 1500rpm | 1500rpm | 1500rpm | 1500rpm | 1500rpm | 1500rpm |
| Fuel Consumption | ≤225g/Kw.h | ≤225g/Kw.h | ≤230g/Kw.h | ≤225g/Kw.h | ≤225g/Kw.h | ≤225g/Kw.h |
| Cooling Method | Closed Watercooled | Closed Watercooled | Closed Watercooled | Closed Watercooled | Closed Watercooled | Closed Watercooled |
| Starting Way | Electric Start | Electric Start | Electric Start | Electric Start | Electric Start | Electric Start |
| Canopy Silent Type | Silent | Silent | Silent | Silent | Silent | Silent |
| Weight Silent Type | 700kg | |||||
| Size Silent TYpe | 2000*860*1200mm | 2000*860*1200mm | 2000*860*1200mm | 2250*1000*1550mm | 2250*1000*1550mm | 2610*1000*1500mm |
